Outdoor fixed Screen-T10

Energy saving
8000nits
High Stability

High Stability 、 High Brightness 、 Energy Saving

Maintaining stability is of top priority

High Stability and reliability, excellently response to all kinds of harsh environment

Applied over 10 years in the market , High Stability and reliability with various testing such as waterproof testing , salt spray testing , aging testing and seismic testing and etc.

Various pixel pitch for different application

P6.6 P8 P10,the 3 different pixel pitch to meet the needs of different viewing distances

Applications

T series apply to Sports venue, commercial square, railway station square, airport, pedestrian street, station, subway, leisure dock, exhibition hall, etc

High protection

Comprehensive waterproof design, easy to deal with all kinds of harsh environment.

More models for your more needs, please choose your favorite one...

Product Name	T6.6	T8	T10
Pixel Configuration	DIP570	DIP570	DIP570
Pixel Pitch(mm)	6.6	8	10
Pixel matrix per panel	144x144	120x120	96x96
Cabinet Dimensions(mm)	960x960x113	960x960x113	960x960x113
Transparency Rate	/	/	/
Refresh Rate(Hz)	3840	3840	3840
Drive Mode	1/6	1/5	1/4
Brightness (nits)	8000/6000	8000/6000	8000/6000
Horizontal / Vertical Viewing Angle	110/55	110/55	110/55
AC Input Power Maximum/Average	550/185 / 440/150	550/185 / 440/150	550/185 / 440/150

Common Problem

What is the Taurus T Series T10 outdoor fixed screen?

The Taurus T Series T10 outdoor fixed screen is a type of LED display panel designed for outdoor applications. It is a high-quality and reliable display solution that offers superior image quality and performance in various outdoor environments. The T10 refers to the pixel pitch of the screen, which is 10mm, indicating the distance between the pixels on the display.

What is the pixel pitch of the Taurus T Series T10 outdoor fixed screen?

The pixel pitch of the Taurus T Series T10 outdoor fixed screen refers to the distance between the centre of two adjacent pixels on the LED display. The T10 model has a pixel pitch of 10mm, which means that the distance between the centre of two adjacent pixels is 10mm. The smaller the pixel pitch, the higher the pixel density and the better the image clarity, but the cost of the screen is also higher. The T10 model provides a good balance between image quality and cost, making it a popular choice for outdoor fixed installations where high visibility and cost-effectiveness are both important factors.

Is the Taurus T Series T10 outdoor fixed screen waterproof?

Yes, the Taurus T Series T10 outdoor fixed screen is waterproof and has an IP65 rating, which means it is protected against water jets and can withstand harsh weather conditions.

What is the maximum brightness of the Taurus T Series T10 outdoor fixed screen?

The maximum brightness of the Taurus T Series T10 outdoor fixed screen is 6,000 nits, which makes it suitable for use in bright outdoor environments.

What is the viewing angle of the Taurus T Series T10 outdoor fixed screen?

The viewing angle of the Taurus T Series T10 outdoor fixed screen is typically 160 degrees in both horizontal and vertical directions, which ensures that the display can be seen clearly from a wide range of angles.
